Testo 760-2 - Digital Multimeter

Part Number: 0590 7602 Brand: Testo

Testo 760-2 - Digital Multimeter

Price
Request a Quote
Stock
In Stock
Does not ship to VA, United States

The Testo 760-2 digital multimeter is the allrounder for all important electrical measuring tasks.

Thanks to the automatic detection of measurement parameters, it offers the greatest possible reliability for every application.

You can also measure current in the µA range and determine the true root mean square using this digital multimeter.

The Testo 760-2 digital handheld multimeter means you can measure electrical parameters more easily and reliably than ever before.

In contrast to other multimeters, the Testo 760-2 automatically detects the appropriate measurement parameter via the socket assignment – and therefore rules out any dangerous incorrect settings.

It is not operated conventionally by a dial, but with illuminated function keys.

This means you can easily control the measuring instrument with just one hand. The large, illuminated display shows the readings clearly.

The Testo 760-2 digital multimeter has the most important functions for measuring current, voltage and resistance.

The measurement of current strength is also possible in the µA range thanks to the larger measuring range.

And the integrated low-pass filter achieves more accurate measurement results on frequency converter controlled motors.

Temperatures can also be measured with this multimeter in addition to electrical parameters.
Features
  • Easy, reliable work thanks to automatic measurement parameter detection
  • Current measurement in the µA range
  • True root mean square measurement - TRMS
  • Low-pass filter for accurate measurement results on frequency converter controlled motors

Specifications

Brand

Delivery Scope

  • Testo 760-2 TRMS Multimeter, including Batteries, 1 Set of Measuring Cables (0590 0010), 1 x Adapter for Thermocouples Type K and Instruction Manual

Temperature - TC Type K (NiCr-Ni)

  • Measuring Range: -20° C to +500° C
  • Accuracy: ± 1° C (0° C to +100° C)
  • Resolution: 0.2° C

DC Voltage

  • Measuring Range: 0.1 to 600 V
  • Resolution: Max. 0.1 mV
  • Accuracy: ± (0.8 % of mv + 3 Digit)

AC Voltage

  • Measuring Range: 0.1 mV to 600 V
  • Resolution: Max. 0.1 mV
  • Accuracy: ± (1.0 % of mv + 3 Digit)

DC Current

  • Measuring Range: 0.1 µA to 10 A
  • Resolution: Max. 0.1 mA
  • Accuracy: ± (1.5 % of mv + 5 Digit)

AC Current

  • Measuring Range: 0.1 µA to 10 A
  • Resolution: Max. 0.1 µA
  • Accuracy: ± (1.5 % of mv + 5 Digit)

Resistance

  • Resolution: Max. 0.1 Ohm
  • Measuring Range: 0.01 to 60.00 MOhm
  • Accuracy: ± (1.5 % of mv + 3 Digit)

Capacitance

  • Resolution: Max. 0.1 nF
  • Measuring Range: 0.001 nF to 30,000 μF
  • Accuracy: ± (1.5 % of mv + 5 Digit)

Frequency

  • Resolution: Max. 0.1 Hz
  • Measuring Range: 0.001 Hz to 30.00 MHz
  • Accuracy: ± (0.1 % of mv + 1 Digit)

Operating Humidity

  • 0 to 80 %RH

Weight

  • 340 g

Dimensions

  • 167 x 85 x 45 mm

Operating Temperature

  • 14.0° F to 122.0° F / -10° C to +50° C

Product Colour

  • Black

Protection Class

  • IP64

Standards

  • EN 61326-1, EN 61010-2-033, EN 61140

Battery Type

  • 3 AAA Micro Batteries

Display Type

  • LCD (Liquid Crystal Display)

Display Size

  • 2-Lines

Interface

  • 4 Measuring Jacks

Storage Temperature

  • 5.0° F to 140.0° F / -15° C to +60° C

Overvoltage Category

  • CAT III 1000 V, CAT IV 600 V

Authorizations

  • CSA, CE

Internal Resistance

  • 11 MOhm (AC / DC)

Instrument Measurement Functions

  • Diode Test: Yes
  • Current Probe Measurement with Adapter: Yes
  • Temperature Measurement with Adapter: Yes
  • True RMS: Yes
  • Low-Pass Filter: Yes
  • Duty Cycle Measurement: Yes
  • μA Current Measuring Range: Yes
  • Continuity Testing: Yes
  • Display Lighting: Yes
  • Hold: Yes
  • Min/Max.: Yes
  • Display (Counts): 4,000
  • Automatic Measurement Parameter Detection: Yes

  • Ideal for Measuring all Important Electrical Parameters
    • Automatic Detection and Selection of Measurement Parameters
    • Current Measurement in the µA range
    • True Root Mean Square (TRMS) Measurement
    • Low Pass Filter
    • Operation via Function Keys
    • Large Illuminated Display
    • Temperature Adapter
  • Overview of Applications
    • Testing Voltage Supply in Live Wires
    • Current Measurement in the Lower Measuring Range
    • Testing Voltage Supply for Frequency-Controlled Motors
    • Measuring the Ionization Flow of Heating Systems
    • Continuity Tests on Switching Components
    • Resistance Measurement of Sensors or Motor Windings
    • Easy Temperature Checking
